Double-layer AL/PET Laminated Film

Color: Silver, blue, red, green, customized

PET Thickness: 12mic, 15mic, 23mic, 25mic

Width: 5mm-1000mm

ID: 52mm/76mm

OD: ≤800mm

Packaging: Carton box

Product Introduction

Double-layer AL/PET laminated film is a composite material mainly used in the cable industry. Its composition is:

  • Aluminum foil: reflection and protection.
  • PET: strength and durability.
  • Aluminum foil: anti-static, insulation.

Double-layer aluminum foil + PET film is composed of aluminum foil and polyester film, which are laminated together by dry lamination, and then slit and rolled. Common colors are silver and blue, and other colors, printing, or textures can also be customized according to customer needs.

Product Specifications

Specification Composition Elongation (%) Tensile strength (Mpa) Basis weight (g/m²) Peel strength (N/cm)
AL PET AL
32μm 7μm 12μm 7μm 35↑ 6.3↑ 61±10% 6.3↑
35μm 7μm 15μm 7μm 35↑ 6.3↑ 65±10% 6.3↑
36μm 9μm 12μm 9μm 35↑ 6.3↑ 74±10% 6.3↑
49μm 9μm 25μm 9μm 35↑ 60↑ 92±10% 6.3↑
55μm 12μm 15μm 12μm 35↑ 60↑ 94±10% 6.3↑
53μm 12μm 23μm 12μm 35↑ 60↑ 105±10% 6.3↑
61μm 15μm 25μm 15μm 20↑ 60↑ 122±10% 6.3↑
In addition to the above specifications, other   special requirements can be designed according to customers

Product Applications

  1. Signal cable
    Shielded cable: used to prevent electromagnetic interference (EMI), double-sided aluminum foil provides an effective shielding effect to ensure the stability of signal transmission.
  2. Communication cable
    Fiber optic cable: used as a protective layer in fiber optic cable to prevent the external environment from affecting signal quality while providing physical protection.
  3. Power cable
    High-voltage cable: in high-voltage cable, the aluminum foil layer can enhance insulation performance and provide additional protection against moisture and external damage.
  4. Industrial equipment cable
    Automation equipment cable: used for factory automation equipment, providing good wear resistance and anti-interference capabilities.

Double-layer AL PET Laminated Film for Cables





Product & Packaging Photos
